sunrise AlS Series

Automatic Channel Processing System

The Sunrise Channel Line System – ACPS – is a versatile and fully automated channel line solution that efficiently processes channel webs from C3 to C6. It offers punching, shearing, and marking capabilities, enhancing accuracy and productivity in metal fabrication applications.

Operation: The operator loads the channel onto the all-steel in-feed rollers; the system engages and pneumatically clamps the material, measures the length, and then processes the material by automatically punching the web and shearing (with a 1/2″ slug) to length utilizing the industrial strength rack and pinion drive system. When the bar is complete, the system will automatically retract, drop the 6″ scrap, and move to the load position to repeat the process.

Capacities:

  • Shearing – 160 Ton Shear:
    • Channel: 3″ – 6″ | C3-C6
    • Optional Flat Bar: 2″ x 1/4″ up to 6″ x 1/2″  – No Slug Loss
  • Punching – Single 88-Ton Punching Cylinder on Linear Rails
    • 1.5″ up to the rated tonnage – Material – 65,000 PSI Tensile.
    • Two independent punches – each programmable for web-only punching.
  • Positioning Speed: Up to 50′ per Minute – Variable Speed
  • Accuracy: +/- 0.006″/ Foot
  • In-Feed Length: 20′ Standard – Expandable to 50′.
Let us customize a machine, just for you

Industries and Applications:

  • Channel clips, brackets, bracing bars, and more
  • Tower builders, track and rail
  • Truck Chassis, lawnmowers

Get to know the ACPS Series

Standard Features
  • Touch-Screen Windows Controller featuring multi-program memory, nesting ability, multiple pattern templates, DXF/NC1 Import, TeamViewer Remote Diagnostics, WiFi, USB
  • 20′ Standard In-Feed with Rack-and-Pinion Drive System, expandable up to 50′
  • Hydraulic punch stripper, hydraulic hold-down for shearing, and pneumatic hold-downs for in-feed
  • Dual Punch Feature – Two independent punches, up to 1.5″ capacity.
  • 0.50″ slug loss per cut featuring multi-sided blades, adjustable blade gap
  • Automatic Pneumatic Material Clamping and Squaring
  • Fully enclosed punching and shearing operations for operator safety, interlocked doors.
  • Integrated cooling system with hydraulic oil cooler and filter
