ROUNDO PASS 310/8 CNC – REFURBISHED

TECHNICAL DATA
Capacities in carbon steel Type A-36:
Prebending capacity: 8′ x 1/2″ to 17″ ID with a flat end of 3/4″ – 1″
Circular rolling capacity to 60″ ID: 8′ x 11/16″
Circular rolling capacity to 120″ ID: 8′ x 7/8″
Capacities in stainless steel:
Prebending capacity: 8′ x 3/8″ to 18″ ID with a flat end of 5/8″-3/4″
Circular rolling capacity to 60″ ID: 8′ x 5/8″
Circular rolling capacity to 120″ ID: 8′ x 11/16″
Diameter of the top roll: 12.20” (310 mm)
Diameter of the lower roll: 12.20” (310 mm)
Diameter of the two side rolls: 10.43” (265 mm)
Total connected motor power @ 480 volts – 20 HP
Rolling speed: 0 – 23’ per minute, infinitely variable
Approximate net weight – 28,000 pounds

• 4-Roll Double Pinch Plate Roll
• Hydraulic Drop End
• Hardened Rolls
• SweBend CNC Retrofit
• Hydraulic Drive with Variable Speed
• 8′ x 3/4″ Mild Steel Rolling Capacity
